16A Suntree DC Link with 1 Pole Holder – Compact Protection for DC Solar Circuits The 16A Suntree DC Link with 1 Pole Holder is a compact, high-performance fuse holder engineered for use in low-to-medium current DC applications. Rated for...
The 16A Suntree DC Link with 1 Pole Holder is a compact, high-performance fuse holder engineered for use in low-to-medium current DC applications. Rated for up to 1000V DC and 16A, it offers reliable protection and isolation for solar PV circuits. Ideal for solar charge controllers, hybrid inverters, and string protection, this fuse holder ensures safe operation and easy maintenance.
With its 1-pole holder design, it fits seamlessly into tight control panels or DC combiner boxes. Its robust construction—featuring flame-retardant housing and copper contacts—delivers long-lasting protection for off-grid and grid-tied solar systems.
| Feature | Details |
|---|---|
| Rated Current | 16A |
| Rated Voltage | Up to 1000V DC |
| Number of Poles | 1 Pole |
| Protection Type | Overcurrent and Circuit Isolation |
| Mounting Type | 35mm DIN Rail Compatible |
| Compatible Fuse Size | 10x38mm (fuse not included) |
| Material | Flame-Retardant Thermoplastic + Copper Contacts |
| Operating Temperature | -30°C to +70°C |
| Compliance | IEC 60269-6, CE, RoHS |
| Torque (Terminal) | 2.0 – 3.5 Nm |
| Humidity Range | ≤ 95% RH |
| Altitude Limit | ≤ 2000 meters |
| Weight | Approx. 0.07 kg |
Optimized for DC Solar Circuits
Delivers efficient current protection for PV applications, especially with 16A-rated DC strings.
Space-Saving Installation
The 1-pole holder design fits easily into compact enclosures and combiner boxes.
Durable Construction
Built with industrial-grade plastic and copper for heat resistance and longevity.
Fast Integration
DIN rail mounting and snap-fit holder allow for quick setup and easy maintenance access.
Protection of individual solar strings
Fuse protection for DC loads in off-grid homes
Hybrid inverter DC side protection
Backup battery DC line isolation
Solar charge controller input protection
Ensure system is powered down before handling
Mount onto a standard 35mm DIN rail
Insert appropriate 10x38mm fuse (16A)
Tighten terminal screws securely and check polarity
Confirm connections and test before system reactivation
